MS Plate

• Application
• Other, Construction, Fabrication, Shipbuilding, Bridges, Heavy Equipment Manufacturing

• Coating Type
• Uncoated / Custom on request (e.g., galvanized, painted)

• Color
• Grey / Metallic

• Composition
• Fe, C, Mn, S, P, Si

• Corrosion Resistant
• Moderate, requires painting or coating for enhanced resistance

• Diameter
• Not applicable (plate form)

• Dimension (L*W*H)
• As per requirement / 2500 mm x 1250 mm (standard)

• Finish Type
• Hot Rolled, Mill Finish

• Grade
• IS 2062 E250, E350 or as required

• Hardness
• 120 - 180 HB (Brinell Hardness)

• Heat Resistance
• Yes

• Material Composition %
• C: 0.2%, Mn: 0.9%, S: 0.045%, P: 0.045% (approx)

• Material Grade
• IS 2062, ASTM A36, S235JR

• Product Form
• Plate

• Product Name
• Other, MS Plate

• Recyclable
• Yes

• Shape
• Other, Rectangular

• Size
• Custom sizes or standard (e.g., 8ft x 4ft, 10ft x 5ft)

• Steel Product Type
• Other, Steel Plate

• Steel Standard
• Other, IS 2062, ASTM A36, EN10025

• Steel Type
• Mild Steel

• Surface
• Hot Rolled

• Tensile Strength
• 410 - 580 MPa (varies by grade)

• Thickness
• 2 mm to 150 mm

• Usage
• Structural, Industrial, Commercial

• Weight
• Varies as per size and thickness; e.g., standard plate ~78.5 kg/m2 at 10 mm thickness

• Application
• Other, Boiler and Pressure Vessel fabrications, petrochemical, oil, and gas industries

• Coating Type
• Uncoated / as per order

• Color
• Grey / Black

• Composition
• Carbon, Manganese, Phosphorus, Sulfur, Silicon

• Corrosion Resistant
• Moderate, suited for pressure vessels

• Dimension (L*W*H)
• As per customer requirement

• Finish Type
• Mill Finish

• Grade
• ASTM A516 Grade 70

• Hardness
• 170 - 207 BHN

• Heat Resistance
• Yes

• Material Composition %
• C: 0.27%, Mn: 0.85-1.20%, Si: 0.15-0.40%, S: 0.035%, P: 0.035%

• Material Grade
• A516 Grade 70

• Product Form
• Plate

• Product Name
• Other, 516 Grade 70 Boiler Plate

• Recyclable
• Yes

• Shape
• Other, Rectangular Plate

• Size
• Customizable as per requirement

• Steel Product Type
• Other, Boiler Plate

• Steel Standard
• Other, ASTM A516 / ASME SA516

• Steel Type
• Carbon Steel

• Surface
• Hot Rolled, Mill Finish

• Tensile Strength
• 485 - 620 MPa

• Thickness
• 6 mm to 150 mm

• Usage
• For boilers, heat exchangers, storage tanks, pressure vessels

• Weight
• As per standard and size specification
